Aluminum Electrolytic Capacitors,Capacitors- Page 1110

Datasheet	Mfr. Part #	Stock	Price	Quantity	Packaging	Series	ProductStatus	Capacitance	Tolerance	Voltage-Rated	ESR(EquivalentSeriesResistance)	Lifetime@Temp	OperatingTemperature	Polarization	Ratings	Applications	RippleCurrent@LowFrequency	RippleCurrent@HighFrequency	Impedance	LeadSpacing	Size/Dimension	Height-Seated(Max)	SurfaceMountLandSize	MountingType
Datasheet	EEE-TK1E221P CAP ALUM 220UF 20% 25V SMD Panasonic Electronic Components	2782	1.59	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	TK	Active	220 µF	±20%	25 V	200mOhm @ 100kHz	3000 Hrs @ 125°C	-40°C ~ 125°C	Polar	-	General Purpose	175.5 mA @ 120 Hz	270 mA @ 100 kHz	-	-	0.394 Dia (10.00mm)	0.402 (10.20mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
Datasheet	EEE-TK1E331UP CAP ALUM 330UF 20% 25V SMD Panasonic Electronic Components	3061	1.59	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	TK	Active	330 µF	±20%	25 V	200mOhm @ 100kHz	3000 Hrs @ 125°C	-40°C ~ 125°C	Polar	-	General Purpose	175.5 mA @ 120 Hz	270 mA @ 100 kHz	-	-	0.394 Dia (10.00mm)	0.402 (10.20mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
Datasheet	EEE-TK1V101P CAP ALUM 100UF 20% 35V SMD Panasonic Electronic Components	2958	1.59	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	TK	Active	100 µF	±20%	35 V	200mOhm @ 100kHz	3000 Hrs @ 125°C	-40°C ~ 125°C	Polar	-	General Purpose	175.5 mA @ 120 Hz	270 mA @ 100 kHz	-	-	0.394 Dia (10.00mm)	0.402 (10.20mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
Datasheet	EEU-EB1E331 CAP ALUM 330UF 20% 25V RADIAL Panasonic Electronic Components	3607	0.71	- + Add To Cart Inquiry Now	Bulk	EB-A	Active	330 µF	±20%	25 V	-	10000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	255 mA @ 120 Hz	331.5 mA @ 100 kHz	-	0.138 (3.50mm)	0.315 Dia (8.00mm)	0.630 (16.00mm)	-	Through Hole
Datasheet	UPW1J121MPD CAP ALUM 120UF 20% 63V RADIAL Nichicon	3163	0.71	- + Add To Cart Inquiry Now	Bulk	UPW	Not For New Designs	120 µF	±20%	63 V	-	5000 Hrs @ 105°C	-55°C ~ 105°C	Polar	-	General Purpose	390 mA @ 120 Hz	600 mA @ 100 kHz	194 mOhms	0.197 (5.00mm)	0.394 Dia (10.00mm)	0.630 (16.00mm)	-	Through Hole
Datasheet	ELXY250ELL151MH12D CAP ALUM 150UF 20% 25V RADIAL United Chemi-Con	1790	0.71	- + Add To Cart Inquiry Now	Bulk	LXY	Active	150 µF	±20%	25 V	-	3000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	178 mA @ 120 Hz	445 mA @ 100 kHz	170 mOhms	0.138 (3.50mm)	0.315 Dia (8.00mm)	0.531 (13.50mm)	-	Through Hole
Datasheet	UCD0J681MNL1GS CAP ALUM 680UF 20% 6.3V SMD Nichicon	2992	0.75	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	UCD	Not For New Designs	680 µF	±20%	6.3 V	-	5000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	300 mA @ 120 Hz	600 mA @ 100 kHz	160 mOhms	-	0.315 Dia (8.00mm)	0.413 (10.50mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
Datasheet	UWZ1H151MCL1GS CAP ALUM 150UF 20% 50V SMD Nichicon	3472	0.75	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	UWZ	Active	150 µF	±20%	50 V	-	1000 Hrs @ 105°C	-55°C ~ 105°C	Polar	-	High Temperature Reflow	180 mA @ 120 Hz	270 mA @ 10 kHz	-	-	0.394 Dia (10.00mm)	0.394 (10.00mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
Datasheet	860020375018 CAP ALUM 1200UF 20% 16V RADIAL Würth Elektronik	2194	0.52	- + Add To Cart Inquiry Now	Cut Tape (CT),Tape & Box (TB)	WCAP-ATG5	Active	1200 µF	±20%	16 V	-	2000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	700 mA @ 120 Hz	896 mA @ 100 kHz	-	0.197 (5.00mm)	0.394 Dia (10.00mm)	0.846 (21.50mm)	-	Through Hole
Datasheet	AFK226M35C12T-F CAP ALUM 22UF 20% 35V SMD Cornell Dubilier Electronics (CDE)	2384	0.90	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	AFK	Active	22 µF	±20%	35 V	700mOhm @ 100kHz	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive, Bypass, Decoupling	120 mA @ 120 Hz	160 mA @ 100 kHz	700 mOhms	-	0.197 Dia (5.00mm)	0.240 (6.10mm)	0.209 L x 0.256 W (5.30mm x 6.50mm)	Surface Mount
Datasheet	AFK336M10C12T-F CAP ALUM 33UF 20% 10V SMD Cornell Dubilier Electronics (CDE)	3505	0.90	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	AFK	Active	33 µF	±20%	10 V	700mOhm @ 100kHz	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive, Bypass, Decoupling	120 mA @ 120 Hz	160 mA @ 100 kHz	700 mOhms	-	0.197 Dia (5.00mm)	0.240 (6.10mm)	0.209 L x 0.256 W (5.30mm x 6.50mm)	Surface Mount
Datasheet	AFK336M25C12T-F CAP ALUM 33UF 20% 25V SMD Cornell Dubilier Electronics (CDE)	3340	0.90	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	AFK	Active	33 µF	±20%	25 V	700mOhm @ 100kHz	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive, Bypass, Decoupling	120 mA @ 120 Hz	160 mA @ 100 kHz	700 mOhms	-	0.197 Dia (5.00mm)	0.240 (6.10mm)	0.209 L x 0.256 W (5.30mm x 6.50mm)	Surface Mount
Datasheet	UWZ1E331MCL1GS CAP ALUM 330UF 20% 25V SMD Nichicon	2372	0.75	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	UWZ	Active	330 µF	±20%	25 V	-	1000 Hrs @ 105°C	-55°C ~ 105°C	Polar	-	High Temperature Reflow	190 mA @ 120 Hz	285 mA @ 10 kHz	-	-	0.394 Dia (10.00mm)	0.394 (10.00mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
Datasheet	UCD0J102MNL1GS CAP ALUM 1000UF 20% 6.3V SMD Nichicon	3344	0.76	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	UCD	Not For New Designs	1000 µF	±20%	6.3 V	-	5000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	300 mA @ 120 Hz	600 mA @ 100 kHz	160 mOhms	-	0.315 Dia (8.00mm)	0.413 (10.50mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
Datasheet	ULT2D270MNL1GS CAP ALUM 27UF 20% 200V SMD Nichicon	3605	1.36	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	ULT	Active	27 µF	±20%	200 V	-	2000 Hrs @ 125°C	-40°C ~ 125°C	Polar	-	General Purpose	65 mA @ 120 Hz	97.5 mA @ 10 kHz	-	-	0.394 Dia (10.00mm)	0.571 (14.50mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
Datasheet	35TKV68M6.3X8 CAP ALUM 68UF 20% 35V SMD Rubycon	3991	0.85	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	TKV	Active	68 µF	±20%	35 V	160 mohm @ 100kHz	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	264 mA @ 120 Hz	600 mA @ 100 kHz	-	-	0.248 Dia (6.30mm)	0.315 (8.00mm)	0.260 L x 0.260 W (6.60mm x 6.60mm)	Surface Mount
Datasheet	25TKV100M6.3X8 CAP ALUM 100UF 20% 25V SMD Rubycon	3143	0.85	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	TKV	Active	100 µF	±20%	25 V	160 mohm @ 100kHz	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	264 mA @ 120 Hz	600 mA @ 100 kHz	-	-	0.248 Dia (6.30mm)	0.315 (8.00mm)	0.260 L x 0.260 W (6.60mm x 6.60mm)	Surface Mount
Datasheet	ULR2E220MNL1GS CAP ALUM 22UF 20% 250V SMD Nichicon	3739	1.36	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	ULR	Active	22 µF	±20%	250 V	-	3000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	55 mA @ 120 Hz	88 mA @ 10 kHz	-	-	0.394 Dia (10.00mm)	0.571 (14.50mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
Datasheet	ULH2D220MNL1GS CAP ALUM 22UF 20% 200V SMD Nichicon	3268	1.36	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	ULH	Active	22 µF	±20%	200 V	-	4000 Hrs @ 125°C	-40°C ~ 125°C	Polar	-	General Purpose	65 mA @ 120 Hz	97.5 mA @ 10 kHz	-	-	0.394 Dia (10.00mm)	0.571 (14.50mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
Datasheet	EEE-FK1A221AL CAP ALUM 220UF 20% 10V SMD Panasonic Electronic Components	3122	0.90	- + Add To Cart Inquiry Now	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	FK, Halogen Free	Active	220 µF	±20%	10 V	-	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive, High Temperature Reflow	195 mA @ 120 Hz	300 mA @ 100 kHz	260 mOhms	-	0.315 Dia (8.00mm)	0.256 (6.50mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount

Total 115368 Records«Prev 1... 1106 1107 1108 110911101111 1112 1113...5769 Next»
